WDP34S2ACR Nidec 3/4 hp 1800 RPM 56HC Frame (No Base) 208-230/460V TENV 3-Phase Washdown Motor

WDP34S2ACR Nidec 3/4 hp 1800 RPM 56HC Frame (No Base) 208-230/460V TENV 3-Phase Washdown Motor

This Nidec 3/4 horsepower motor is designed for industrial washdown applications, particularly in food and pharmaceutical environments. It replaces standard motors requiring a durable, paint-free construction with stainless steel components for enhanced corrosion resistance.

Key Specifications

• Horsepower: 3/4 hp
• RPM: 1800
• Voltage: 208-230/460 V
• Amperage: 2.8-2.7/1.3 A
• Enclosure: Totally Enclosed Non-Ventilated (TENV)
• Frame / Diameter: NEMA 56C Rolled Steel Frame
• Shaft Dimensions: 5/8" Diameter x 1 7/8" Length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a C-face mount and a keyed shaft for secure coupling. It is constructed with all stainless steel components except for the side box, ensuring suitability for washdown environments. The motor includes a wiring diagram on the nameplate to facilitate installation.

Warranty

1 Year Manufacturer Warranty
