WDS2P2AFHC Nidec 2 hp 1800 RPM 56HC All-Stainless (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor

WDS2P2AFHC Nidec 2 hp 1800 RPM 56HC All-Stainless (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor

SKU:
WDS2P2AFHC
Weight:
61.00 LBS
Width:
14.00 (in)
Height:
9.00 (in)
Depth:
12.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
208/230/460V
Horsepower:
2 HP
RPM:
1800
Phase:
Three Phase
Enclosure:
TENV
Hertz:
60 Hz
Amperage:
5.4/2.7 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $1,462.80
Now: $1,306.06
Adding to cart… The item has been added
  • 2 hp 1800 RPM, 5.8-5.4/2.7 amps  208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 56HC Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

All Stainless Steel wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TENV = Totally Enclosed Non-Ventilated. DY57

!
