X019 Marathon 1/3 hp 277V 1075 RPM (3 speed) OPAO 48Y Frame Blower Motor

X019 Marathon 1/3 hp 277V 1075 RPM (3 speed) OPAO 48Y Frame Blower Motor

This Marathon blower motor is designed for HVAC applications requiring reliable air movement within buildings. It replaces standard blower motors with a 1/3 horsepower rating and supports three-speed operation for versatile airflow control.

Key Specifications

• Horsepower: 1/3 hp
• RPM: 1075
• Voltage: 277 V
• Amperage: 2.7 A
• Enclosure: Open Open Air Over (OPAO)
• Frame / Diameter: NEMA 48Y Frame
• Shaft Dimensions: Keyed shaft, 1/2" diameter x 4" length
• Rotation: Reversible
• Bearings: Ball bearings

Product Features & Fitment

This motor features a Permanent Split Capacitor (PSC) design with automatic thermal protection and Class B insulation for durability. It comes without a base and is intended for installation in air-stream environments due to its OPAO enclosure type. The motor supports both vertical and horizontal shaft orientations for flexible mounting options.

Warranty

1 Year Manufacturer Warranty
