X097 Marathon 1/4 hp 208-230V 825 RPM OPAO 48Z Frame Condenser Fan Motor
X097 Marathon 1/4 hp 208-230V 825 RPM OPAO 48Z Frame Condenser Fan Motor
X097 Marathon 1/4 hp 208-230V 825 RPM OPAO 48Z Frame Condenser Fan Motor
X097 Marathon 1/4 hp 208-230V 825 RPM OPAO 48Z Frame Condenser Fan Motor
X097 Marathon 1/4 hp 208-230V 825 RPM OPAO 48Z Frame Condenser Fan Motor
X097 Marathon 1/4 hp 208-230V 825 RPM OPAO 48Z Frame Condenser Fan Motor

Marathon

X097 Marathon 1/4 hp 208-230V 825 RPM OPAO 48Z Frame Condenser Fan Motor

(No reviews) Write a Review
$308.32
$266.23
SKU X097
UPC 7.23E+11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 208/230V
Horsepower 1/4 HP
RPM 825
Frame 48Z
Hertz 60 Hz
Amperage 1.8 Amps
Bearings Ball Bearings
Insulation Class Class B
Adding to cart… The item has been added
Description
  • 1/4 hp 825 RPM, 1.8-1.8 amps, 208-230 Volts 60 Hz, Permanent Split Capacitor (PSC)
  • NEMA 48Z Frame Keyed Shaft 1/2" Diameter x 6"
  • Service Factor = 1.0, Thermal Protection = Automatic
  • No Base, Reversible, Ball Bearings, Class B insulation
  • 1 Year Manufacture Warranty

Condenser Fan Motors are used in air conditioning coolant condenser units usually found outdoors. Shaft may be vertical or horizontal. OPAO = Open-Air-Over so motor must be in air-stream. 048A8O182

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 208/230V
Horsepower 1/4 HP
RPM 825
Frame 48Z
Hertz 60 Hz
Amperage 1.8 Amps
Bearings Ball Bearings
Insulation Class Class B
!
