XP0052 TECO-Westinghouse 5 HP 3600 RPM 184T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

XP0052 TECO-Westinghouse 5 HP 3600 RPM 184T Frame Explosion Proof Motor

The XP0052 is a TECO-Westinghouse premium NEMA explosion proof motor designed for industrial applications where explosive gases or grain dust may be present. It is a reliable replacement motor suitable for hazardous environments requiring a totally enclosed fan cooled (TEFC) design.

Key Specifications

• Horsepower: 5 HP
• RPM: 3600
• Voltage: 230/460 V
• Amperage: 11.6/5.81 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: 184T Cast Iron
• Shaft Dimensions: 1 1/8" diameter x 2 3/4" length with key
• Rotation: Reversible
• Bearings: Ball Bearing

Product Features & Fitment

This single-speed, three-phase motor includes a manual overload protector and features insulation class F with a service factor of 1.15. Its cast iron frame ensures durability in demanding industrial settings. The motor is certified explosion proof for Class I Division 1 Groups C and D, and Class II Groups E, F, and G, making it suitable for use in hazardous locations.

Warranty

1 Year Manufacturer Warranty
