XP0106 TECO-Westinghouse 10 HP 1200 RPM 256T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

XP0106 TECO-Westinghouse 10 HP 1200 RPM 256T Frame 230/460V TEFC Cast Iron 3-Ph Explosion Proof Motor

This TECO-Westinghouse explosion proof motor is designed for hazardous environments where explosive gases or grain dust may be present. It is a reliable replacement motor suitable for industrial applications requiring a 10 HP, 1200 RPM, three-phase power source.

Key Specifications

• Horsepower: 10 HP
• RPM: 1200
• Voltage: 230/460 V
• Amperage: 25.2/12.6 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: 256T Cast Iron
• Shaft Dimensions: 1 5/8" diameter x 4 1/8" length with key
• Rotation: Reversible
• Bearings: Ball Bearing

Product Features & Fitment

This motor features a manual overload protector and insulation class F for enhanced durability. It meets explosion proof standards for Class I Division 1 Groups C and D, and Class II Groups E, F, and G, making it suitable for use in environments with flammable gases and dust. The cast iron frame provides robust protection and long service life.

Warranty

1 Year Manufacturer Warranty
