XPV0036C TECO-Westinghouse 3 HP 1200 RPM 213TC Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor
XPV0036C TECO-Westinghouse 3 HP 1200 RPM 213TC Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor
XPV0036C TECO-Westinghouse 3 HP 1200 RPM 213TC Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor
XPV0036C TECO-Westinghouse 3 HP 1200 RPM 213TC Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

TECO WESTINGHOUSE

XPV0036C TECO-Westinghouse 3 HP 1200 RPM 213TC Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

(No reviews) Write a Review
$1,103.98
SKU XPV0036C
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 3 HP
RPM 1200
Phase Three Phase
Frame 213TC
Enclosure TEFC
Hertz 60 Hz
Amperage 7.84/3.92 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
Rotation Reversible
Mounting C-Face
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE NEMA PREMIUM ROUND MOTOR

  • 3 hp 1200 RPM, 1-Speed, 7.84/3.92 amps, 230/460 Volts 60 Hz. Three Phase
  • 213TC Cast Iron Frame, Shaft: 1 3/8" x 3 1/8" with Key
  • Ball Bearing, Reversible Rotation, Overload Protector: Manual
  • Service Factor = 1.15, Insulation Class F
  • Explosion Proof: Class I Div. 1 Group C and D, Class II Groups E, F, and G.
  • 1 Year Manufacture Warranty

Explosion Proof C-Face Motor For Use Where Ever Explosive Gases or Grain Dust May Be Present. Totally Enclosed Fan Cooled (TEFC)

Specifications
Voltage 230/460V
Horsepower 3 HP
RPM 1200
Phase Three Phase
Frame 213TC
Enclosure TEFC
Hertz 60 Hz
Amperage 7.84/3.92 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
Rotation Reversible
Mounting C-Face
!
