Y12S2B Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

Y12S2B Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

SKU:
Y12S2B
Weight:
47.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $639.00
Now: $570.50
Adding to cart… The item has been added
  • 1/2 hp 1800 RPM, 1.8-1.7/0.9 amps  208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 56 Rolled Steel frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.0, Overload protection = Auto
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. 1204

!
