Y12S2B Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
Y12S2B Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
Y12S2B Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
Y12S2B Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

Nidec

Y12S2B Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

(No reviews) Write a Review
$734.85
$656.08
SKU Y12S2B
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 1.7/0.9 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1/2 hp 1800 RPM, 1.8-1.7/0.9 amps  208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 56 Rolled Steel frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.0, Overload protection = Auto
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. 1204

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 1.7/0.9 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting Rigid Base
!
