Y34S2B Nidec 3/4 hp 1800 RPM 56 Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

Y34S2B Nidec 3/4 hp 1800 RPM 56 Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

SKU:
Y34S2B
Weight:
49.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $674.00
Now: $601.70
Adding to cart… The item has been added
  • 3/4 hp 1800 RPM, 2.7/1.3 amps  230/460 Volts 60 Hz Three Phase Motor
  • NEMA 56 Rolled Steel frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.0, Overload protection = Auto
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. 1200

!
