YC1P4B Nidec 1 hp 900 RPM 182T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
YC1P4B Nidec 1 hp 900 RPM 182T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
YC1P4B Nidec 1 hp 900 RPM 182T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
YC1P4B Nidec 1 hp 900 RPM 182T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

Nidec

YC1P4B Nidec 1 hp 900 RPM 182T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

(No reviews) Write a Review
$2,472.50
$2,068.79
SKU YC1P4B
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1 HP
RPM 900
Phase Three Phase
Frame 182T
Enclosure TEFC
Hertz 60 Hz
Amperage 5.1/2.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1 hp 900 RPM, 5.1/2.5 amps  230/460 Volts 60 Hz Three Phase Motor
  • NEMA 182T Cast Iron frame Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FR67

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1 HP
RPM 900
Phase Three Phase
Frame 182T
Enclosure TEFC
Hertz 60 Hz
Amperage 5.1/2.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
