YC1P4B Nidec 1 hp 900 RPM 182T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

SKU:
YC1P4B
Weight:
90.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $1,761.00
Now: $1,572.10
Adding to cart… The item has been added
  • 1 hp 900 RPM, 5.1/2.5 amps  230/460 Volts 60 Hz Three Phase Motor
  • NEMA 182T Cast Iron frame Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FR67
