5835 Nidec | 1/3 hp 1075 RPM 4-Speed 115V; 5.6" Blower Motor

5835 Nidec | 1/3 hp 1075 RPM 4-Speed 115V; 5.6" Blower Motor

This 1/3 horsepower blower motor is designed for furnace applications, offering reliable performance with a 4-speed operation. It serves as a direct replacement for compatible furnace blower motors requiring a 115V power supply and reversible rotation.

Key Specifications

• Horsepower: 1/3 hp
• RPM: 1075
• Voltage: 115V
• Amperage: 4.6 amps
• Enclosure: Open Air Over
• Frame / Diameter: 5 5/8" diameter
• Shaft Dimensions: 6" length x 1/2" diameter
• Rotation: Reversible
• Bearings: Sleeve Bearings

Product Features & Fitment

This motor features a permanent split capacitor design with automatic overload protection and continuous duty rating, suitable for operation in ambient temperatures up to 40°C. It requires a 7.5 MFD 370V capacitor (part #7.5DV) for proper function. The motor includes 36" leads for wiring convenience and comes with 2.25" diameter hub rings plus a kit for 2.5" hubs to ensure proper fitment during installation.

Warranty

1 Year Manufacturer Warranty
