LX7925 Nidec | 1/6 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Fan Motor
LX7925 Nidec | 1/6 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Fan Motor
LX7925 Nidec | 1/6 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Fan Motor
LX7925 Nidec | 1/6 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Fan Motor

Nidec

LX7925 Nidec | 1/6 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Fan Motor

(No reviews) Write a Review
$255.30
$227.69
SKU LX7925
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 1/6 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 1.0 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Clockwise
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 1/6 hp 1075 RPM 1-Speed 208-230V 1.0 amps
  • Shaft 2.25" x 1/2"
  • Rotation CW shaft end
  • 5.6" Diameter
  • Motor case length 3.81"
  • 35" Leads
  • Sleeve Bearings
  • 5MFD 370V Capacitor REQUIRED (Our Part #5DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Totally Enclosed Air Over Enclosure; Class B Insulation; 40C Ambient Temperature. Application Lennox condenser fan motors. K055DUW1262011B, Suggested after market replacement for 68J9701, K55HXDFM-6844, K55HXDUW1262

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 1/6 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 1.0 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Clockwise
Duty Continuous Duty
!
