1859 Nidec | 1/6 hp 1075 RPM -Speed 208-230V; 5.6" Condenser Motor

SKU:: 1859
UPC:
Weight:: 10.00 LBS
Width:: 6.00 (in)
Height:: 6.00 (in)
Depth:: 12.00 (in)
Shipping:: Free Shipping
ON SALE:: LIMITED TIME DISCOUNT
Voltage:: 208/230V
Horsepower:: 0.167 HP
RPM:: 1075
Type:: Permanent Split Capacitor
Amperage:: 1.0 Amps
Bearings:: Sleeve Bearings
Speeds:: 1-Speed
Insulation Class:: Class B
Duty:: Continuous Duty

Current Stock:

Was: $121.90

Now: $109.24

Quantity:

Adding to cart… The item has been added

Description
Literature
Compliance & Restrictions

1859 Nidec | 1/6 hp 1075 RPM -Speed 208-230V; 5.6" Condenser Motor

This 1/6 horsepower condenser motor is designed for HVAC applications requiring reliable, continuous duty performance. It replaces standard condenser motors with similar specifications and is ideal for use in air conditioning and refrigeration systems.

Key Specifications

Horsepower: 1/6 hp
RPM: 1075
Voltage: 208-230V
Amperage: 1.0 amps
Enclosure: Totally Enclosed Air Over (TEAO)
Frame / Diameter: 5.6" diameter
Shaft Dimensions: 1/2" x 5"
Rotation: Reversible
Bearings: Sleeve bearings

Product Features & Fitment

This permanent split capacitor motor includes automatic overload protection and is rated for continuous duty with Class B insulation suitable for 60°C ambient temperatures. Installation requires a 5 MFD 370V capacitor (part #5DV) for proper operation. The motor case length measures 3.8" and it comes with 30" leads for easy wiring.
