1888 Nidec | 1 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor

SKU:: 1888
UPC:
Weight:: 25.00 LBS
Width:: 6.00 (in)
Height:: 6.00 (in)
Depth:: 14.00 (in)
Shipping:: Free Shipping
ON SALE:: LIMITED TIME DISCOUNT
Voltage:: 208/230V
Horsepower:: 1 HP
RPM:: 1075
Type:: Permanent Split Capacitor
Amperage:: 5.2 Amps
Bearings:: Ball Bearings
Speeds:: 1-Speed
Insulation Class:: Class B
Rotation:: Reversible
Mounting:: Stud
Duty:: Continuous Duty

Current Stock:

Was: $497.95

Now: $444.48

Quantity:

Adding to cart… The item has been added

Description
Literature
Compliance & Restrictions

1888 Nidec | 1 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor

This 1 horsepower condenser motor is designed for HVAC applications requiring reliable, continuous duty performance. It replaces standard 1-speed motors and is suitable for both shaft up and horizontal mounting configurations.

Key Specifications

Horsepower: 1 hp
RPM: 1075
Voltage: 208-230V
Amperage: 5.2 amps
Enclosure: Open Drip-Proof Air Over
Frame / Diameter: 5.6" diameter
Shaft Dimensions: 1/2" x 6"
Rotation: Reversible
Bearings: Ball bearings

Product Features & Fitment

This permanent split capacitor motor includes automatic overload protection and operates with Class B insulation rated for 60°C ambient temperature. It features a stud mount design and comes with 30" leads for easy electrical connections. A 15 MFD 370V capacitor (Part #15DV) is required for operation but is not included.
