120043.00 Leeson | 1 hp 1140 RPM 145T Frame TEFC 115/208-230 Volts
120043.00 Leeson | 1 hp 1140 RPM 145T Frame TEFC 115/208-230 Volts
120043.00 Leeson | 1 hp 1140 RPM 145T Frame TEFC 115/208-230 Volts
120043.00 Leeson | 1 hp 1140 RPM 145T Frame TEFC 115/208-230 Volts
120043.00 Leeson | 1 hp 1140 RPM 145T Frame TEFC 115/208-230 Volts
120043.00 Leeson | 1 hp 1140 RPM 145T Frame TEFC 115/208-230 Volts

Leeson

120043.00 Leeson | 1 hp 1140 RPM 145T Frame TEFC 115/208-230 Volts

(No reviews) Write a Review
$1,154.60
$978.42
SKU 120043
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 115/208/230V
Horsepower 1 HP
RPM 1140
Phase Single Phase
Frame 145T
Enclosure TEFC
Hertz 60 Hz
Amperage 6.7/13.4 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class B
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1 hp 1140 RPM, 6.7/13.4 amps 115/208-230 Volts 60hz. single Phase Motor
  • NEMA 145T Frame Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.0 - overload protection = None
  • Reversible - Rigid Base Mount - Ball Bearings - Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase Electric motor. Motor has a rigid base mount with a keyed shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled.

REF: C145K11FB1F, 120043.00

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 115/208/230V
Horsepower 1 HP
RPM 1140
Phase Single Phase
Frame 145T
Enclosure TEFC
Hertz 60 Hz
Amperage 6.7/13.4 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class B
Mounting Rigid Base
!
