D10P2H Nidec | 10 hp 1800 RPM 215T Frame 200V ODP Electric Motor Nidec

D10P2H Nidec | 10 hp 1800 RPM 215T Frame 200V ODP Electric Motor

This 10 hp, 1800 RPM three-phase electric motor by Nidec is designed for general-purpose industrial applications. It serves as a reliable replacement for motors requiring a NEMA 215T frame and 200V operation, suitable for continuous duty in various settings.

Key Specifications

• Horsepower: 10 hp
• RPM: 1800
• Voltage: 200V
• Amperage: 28.1 amps
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 215T
• Shaft Dimensions: 1-3/8" diameter x 3-3/8" length, keyed
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a rigid base mount and Class F insulation, supporting operation in ambient temperatures up to 40°C. It includes a wiring diagram on the nameplate for ease of installation. This premium efficient motor has a service factor of 1.15 and is designed without built-in overload protection.

Warranty

1 Year Manufacturer Warranty
