sale
Marathon
GT0086 Marathon 100 hp 3600 RPM 365TS Frame 230/460V Open Drip Marathon Electric Motor
(No reviews)
Write a Review
Write a Review
Marathon
GT0086 Marathon 100 hp 3600 RPM 365TS Frame 230/460V Open Drip Marathon Electric Motor
$4,797.69
$4,077.67
SKU
MGT0086
UPC
7.23E+11
Availability
Please email to inquiry for lead time
Shipping
Calculated at Checkout
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
LIMITED TIME DISCOUNT
Voltage
230/460V
Horsepower
100 HP
RPM
3600
Phase
Three Phase
Frame
365TS
Enclosure
ODP
Hertz
60 Hz
Amperage
227.0/114.0 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class F
Mounting
Rigid Base
- 100 hp 3600 RPM, 227.0/114.0 amps 230/460 Volts 60hz. Three Phase Motor
- NEMA 365TS Frame Keyed Shaft 1 7/8 " Diameter x 3 3/4"
- Service Factor: 1.15 - overload protection = None
- Reversible - Rigid Base Mount - Ball Bearings - Class F Insulation
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a three phase Electric motor. Motor has a rigid base mount with a keyed shaft. Wiring diagram on motor name plate. ODP = Open Drip Proof.
365TSTDBD6001 Replaces Leeson 170151.60, B199722.00; Dayton 454X75
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | LIMITED TIME DISCOUNT |
| Voltage | 230/460V |
| Horsepower | 100 HP |
| RPM | 3600 |
| Phase | Three Phase |
| Frame | 365TS |
| Enclosure | ODP |
| Hertz | 60 Hz |
| Amperage | 227.0/114.0 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.15 |
| Insulation Class | Class F |
| Mounting | Rigid Base |
