GT0076 Marathon 50 hp 3600 RPM 324TS Frame 230/460V Open Drip Marathon Electric Motor
GT0076 Marathon 50 hp 3600 RPM 324TS Frame 230/460V Open Drip Marathon Electric Motor
GT0076 Marathon 50 hp 3600 RPM 324TS Frame 230/460V Open Drip Marathon Electric Motor
GT0076 Marathon 50 hp 3600 RPM 324TS Frame 230/460V Open Drip Marathon Electric Motor
GT0076 Marathon 50 hp 3600 RPM 324TS Frame 230/460V Open Drip Marathon Electric Motor
GT0076 Marathon 50 hp 3600 RPM 324TS Frame 230/460V Open Drip Marathon Electric Motor

Marathon

GT0076 Marathon 50 hp 3600 RPM 324TS Frame 230/460V Open Drip Marathon Electric Motor

(No reviews) Write a Review
$2,915.25
$2,478.25
SKU MGT0076
UPC 7.23E+11
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 50 HP
RPM 3600
Phase Three Phase
Frame 324TS
Enclosure ODP
Hertz 60 Hz
Amperage 115.0/55.7 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 50 hp 3600 RPM, 115.0/55.7 amps 230/460 Volts 60hz. Three Phase Motor
  • NEMA 324TS Frame Keyed Shaft 1 7/8 " Diameter x 3 3/4"
  • Service Factor: 1.15 - overload protection = None
  • Reversible - Rigid Base Mount - Ball Bearings - Class F Insulation
  • Rolled Steel Construction
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase Electric motor. Motor has a rigid base mount with a keyed shaft. Wiring diagram on motor name plate. ODP = Open Drip Proof.

324TSTDBD6001 Replaces Leeson 170040.60, B199713.00, 199713.00; Dayton 454X66

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 50 HP
RPM 3600
Phase Three Phase
Frame 324TS
Enclosure ODP
Hertz 60 Hz
Amperage 115.0/55.7 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
