GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor
GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor
GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor
GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor
GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor
GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor
GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor
GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor

Marathon

GT2459 Marathon 15 hp 1760 RPM 254JP Frame ODP 230/460V Marathon Close Couple Motor

(No reviews) Write a Review
$2,570.25
$2,029.75
SKU GT2459
UPC 7.23E+11
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
Voltage 230/460V
Horsepower 15 HP
RPM 1760
Phase Three Phase
Frame 254JP
Enclosure ODP
Hertz 60 Hz
Amperage 36.5/18.3 Amps
Insulation Class Class F
Mounting Rigid Base
Duty Continuous duty
Adding to cart… The item has been added
Description
  • 15 hp 1760 RPM 254JP Frame, 36.5/18.3 amps 230/460V 60hz. Three Phase Motor
  • Close Coupled Pump Motor - Rigid Base
  • Open Drip Proof (ODP) - Service Factor = 1.15
  • Class F Insulation; No Overload Protection
  • Continuous duty
  • One Year Manufacture Warranty

Close Coupled Pump Motor. Designed for continuous duty service on close Coupled pumps. Motor has rigid base. Wiring diagram on motor name plate.

254TTDBD6037 Replaces Model 199787.00, 199787, B199787.00, B199787

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
Voltage 230/460V
Horsepower 15 HP
RPM 1760
Phase Three Phase
Frame 254JP
Enclosure ODP
Hertz 60 Hz
Amperage 36.5/18.3 Amps
Insulation Class Class F
Mounting Rigid Base
Duty Continuous duty
!
