GT0410A Marathon 3 hp 1760 RPM 182JM Frame ODP 230/460V Marathon Close Couple Motor

GT0410A Marathon 3 hp 1760 RPM 182JM Frame ODP 230/460V Marathon Close Couple Motor

The GT0410A is a 3 horsepower, 1760 RPM, three-phase close-coupled motor designed for continuous duty service on close-coupled pumps. It replaces models 199589.00, 199589, B199589.00, B199589, and Dayton 26ZX95, making it a reliable choice for pump motor applications requiring a rigid base mount.

Key Specifications

• Horsepower: 3 hp
• RPM: 1760
• Voltage: 230/460V
• Amperage: 8.0/4.0 amps
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: 182JM

Product Features & Fitment

This motor features a rigid base for secure mounting and is designed specifically for close-coupled pump installations. It includes a wiring diagram on the motor nameplate to assist with proper electrical connections. The motor utilizes Class F insulation and operates at a service factor of 1.15 without built-in overload protection.

Cross Reference

• Model 199589.00, 199589, B199589.00, B199589; Dayton 26ZX95

Warranty

1 Year Manufacturer Warranty
