1821VG Nidec 1 1/2 hp 1140 RPM 208-230/460V 56YZ Frame (Rigid Base) 1-Speed OAO 3-Phase Inverter Motor

1821VG Nidec 1 1/2 hp 1140 RPM 208-230/460V 56YZ Frame (Rigid Base) 1-Speed OAO 3-Phase Inverter Motor

This Nidec 1 1/2 hp motor is designed for commercial condenser fan applications requiring a variable frequency drive. It replaces standard motors with a 56YZ frame and supports 3-phase power systems at 208-230/460V.

Key Specifications

• Horsepower: 1 1/2 hp
• RPM: 1140
• Voltage: 208-230/460V
• Amperage: 5.3-5.3/2.6 amps
• Enclosure: Open Air-Over (OAO)
• Frame / Diameter: NEMA 56YZ, Rolled Steel
• Shaft Dimensions: 5/8" diameter x 4 7/8" long, flat and keyed
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base mount for stable installation and includes a thermostat for overload protection. It is equipped with Class F insulation and comes with a wiring diagram located on the motor nameplate to facilitate proper connection with variable frequency drives.

Warranty

1 Year Manufacturer Warranty
