3-3V250-JA Pulley | 2.50" OD Three Groove Pulley / Sheave for 3V V-Belt (bushing not included)

SKU:: 3-3V250-JA
UPC:: 6.63E+11
Weight:: 2.00 LBS
Width:: 6.00 (in)
Height:: 6.00 (in)
Depth:: 6.00 (in)
Shipping:: Free Shipping
Pulley Type:: Bushing Type
Belt Section:: 3V
Grooves:: 3
Bore Size:: Bushing Required
Pitch Diameter:: Under 3"
Material:: Cast Iron

Current Stock:

Was: $35.96

Now: $33.06

Quantity:

Adding to cart… The item has been added

Description
Literature

3-3V250-JA Pulley | 2.50" OD Three Groove Pulley / Sheave for 3V V-Belt

This 3-3V250-JA pulley is a three-groove cast iron sheave designed for use with 3V V-belts. It serves as a replacement pulley compatible with QTL quick detachable taper bushings, ideal for various industrial motor and HVAC applications.

Key Specifications

Frame / Diameter: 2.50" OD

Product Features & Fitment

The pulley requires a "JA" style bushing for proper installation, which is not included. It uses QTL quick detachable taper bushings to facilitate mounting. Depending on the diameter selected, the pulley may be solid or spoked to reduce weight. For assistance in selecting the correct bushing, please contact Electric Motor Warehouse. Note that the product image is a general representation and actual pulley design may vary.
