3742 Nidec | 3/4 hp 1075 RPM 1-Speed 460V; 5.6" Condenser Motor
3742 Nidec | 3/4 hp 1075 RPM 1-Speed 460V; 5.6" Condenser Motor
3742 Nidec | 3/4 hp 1075 RPM 1-Speed 460V; 5.6" Condenser Motor
3742 Nidec | 3/4 hp 1075 RPM 1-Speed 460V; 5.6" Condenser Motor

Nidec

3742 Nidec | 3/4 hp 1075 RPM 1-Speed 460V; 5.6" Condenser Motor

(No reviews) Write a Review
$232.30
$206.99
SKU 3742
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 3/4 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 2.0 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 3/4 hp 1075 RPM 1-Speed 460V 2.0 amps
  • Shaft 1/2" x 6"
  • Rotation = Reversible
  • 5.6" Diameter
  • Motor case length 6.4"
  • Ball bearings
  • 10MFD 370V Capacitor REQUIRED (Our Part #10DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Totally Enclosed Air Over Enclosure; Class B Insulation; 60C Ambient Temperature; 30" Leads, K055TDR8455014B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 3/4 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 2.0 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Duty Continuous Duty
!
