2202 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230/460V; 5.6" Condenser Motor

2202 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230/460V; 5.6" Condenser Motor

SKU:
2202
Weight:
22.13 LBS
Width:
6.00 (in)
Height:
6.00 (in)
Depth:
14.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
208/230/460V
Horsepower:
3/4 HP
RPM:
1075
Type:
Permanent Split Capacitor
Amperage:
4.6/2.3 Amps
Bearings:
Ball Bearings
Speeds:
1-Speed
Insulation Class:
Class B
Rotation:
Reversible
Duty:
Continuous Duty
Was: $562.35
Now: $501.63
Adding to cart… The item has been added
  • 3/4 hp 1075 RPM 1-Speed 208-230/460V 4.6/2.3 amps
  • Shaft 1/2" x 5"
  • Rotation: Reversible
  • 5.6" Diameter
  • Motor case length 8.0"
  • Ball bearings
  • Resilient Rings
  • 12.5MFD 370V Capacitor REQUIRED (Our Part #12.5DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Totally-Enclosed Air OverEnclosure; Class B Insulation; 40C Ambient Temperature; K055SYD7993012B

!
