2202 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230/460V; 5.6" Condenser Motor
2202 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230/460V; 5.6" Condenser Motor
2202 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230/460V; 5.6" Condenser Motor
2202 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230/460V; 5.6" Condenser Motor

Nidec

2202 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230/460V; 5.6" Condenser Motor

(No reviews) Write a Review
$562.35
$501.63
SKU 2202
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3/4 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 4.6/2.3 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Reversible
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 3/4 hp 1075 RPM 1-Speed 208-230/460V 4.6/2.3 amps
  • Shaft 1/2" x 5"
  • Rotation: Reversible
  • 5.6" Diameter
  • Motor case length 8.0"
  • Ball bearings
  • Resilient Rings
  • 12.5MFD 370V Capacitor REQUIRED (Our Part #12.5DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Totally-Enclosed Air OverEnclosure; Class B Insulation; 40C Ambient Temperature; K055SYD7993012B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3/4 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 4.6/2.3 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Reversible
Duty Continuous Duty
!
