6603 Nidec | 3/4 hp 1075 RPM 1-Speed 208-23/460V; 5.6" Condenser Motor

SKU:
6603
Availability:
Subject to availability
Weight:
22.60 LBS
Shipping:
Calculated at Checkout
$368.42
  • 3/4 hp 1075 RPM 1-Speed 208-23/460V 5.0/2.5 amps
  • Shaft 1/2" x 5"
  • Rotation: CW shaft end
  • 5.6" Diameter
  • Motor case length 6.88"
  • Ball bearings
  • Resilient Rings
  • Includes 7.5 MFD 2-prong capacitor
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Open Drip Proof Enclosure; Class B Insulation; 40C Ambient Temperature; Conduit box, K055SKD1007892B
