6603 Nidec | 3/4 hp 1075 RPM 1-Speed 208-23/460V; 5.6" Condenser Motor
6603 Nidec | 3/4 hp 1075 RPM 1-Speed 208-23/460V; 5.6" Condenser Motor
6603 Nidec | 3/4 hp 1075 RPM 1-Speed 208-23/460V; 5.6" Condenser Motor
6603 Nidec | 3/4 hp 1075 RPM 1-Speed 208-23/460V; 5.6" Condenser Motor

Nidec

6603 Nidec | 3/4 hp 1075 RPM 1-Speed 208-23/460V; 5.6" Condenser Motor

(No reviews) Write a Review
$595.70
$531.42
SKU 6603
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/23/460V
Horsepower 3/4 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 5.0/2.5 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Clockwise
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 3/4 hp 1075 RPM 1-Speed 208-23/460V 5.0/2.5 amps
  • Shaft 1/2" x 5"
  • Rotation: CW shaft end
  • 5.6" Diameter
  • Motor case length 6.88"
  • Ball bearings
  • Resilient Rings
  • 7.5MFD 370V Capacitor REQUIRED (Our Part #7.5DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Open Drip Proof Enclosure; Class B Insulation; 40C Ambient Temperature; Conduit box, K055SKD1007892B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/23/460V
Horsepower 3/4 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 5.0/2.5 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Clockwise
Duty Continuous Duty
!
