sale
Marathon
K1409 Marathon 3/4 hp 3 phase 3600 RPM 56 Frame 208-230/460V ODP Resilient Mount Marathon Motor
(No reviews)
Write a Review
Write a Review
Marathon
K1409 Marathon 3/4 hp 3 phase 3600 RPM 56 Frame 208-230/460V ODP Resilient Mount Marathon Motor
$452.64
$290.72
SKU
K1409
UPC
7.23E+11
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage
208/230/460V
Horsepower
3/4 HP
RPM
3600
Phase
Three Phase
Frame
56
Enclosure
ODP
Hertz
60 Hz
Amperage
2.6/2.3 Amps
Bearings
Ball Bearings
Service Factor
1.25
Insulation Class
Class B
Mounting
Resilient
- 3/4 hp 3600 RPM, 2.7-2.6/2.3 amps 208-230/460 Volts 60hz. 3 phase Motor
- NEMA 56 Frame Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.25, Overload protection = Auto
- Reversible, Resilient Base Mount, Ball Bearings, Class B Insulation
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a single phase electric motor. Wiring diagram on motor name plate. ODP = Open Drip Proof, 5K37MN252X
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM |
| Voltage | 208/230/460V |
| Horsepower | 3/4 HP |
| RPM | 3600 |
| Phase | Three Phase |
| Frame | 56 |
| Enclosure | ODP |
| Hertz | 60 Hz |
| Amperage | 2.6/2.3 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.25 |
| Insulation Class | Class B |
| Mounting | Resilient |
