119783.00 Leeson | 3 hp 1740 RPM 56HZ 208-230/460V Feather Picker Motor

Leeson 3 hp 1740 RPM 56HZ 208-230/460V Feather Picker Motor (SKU: 119783)

This Leeson Washguard motor is designed as a premium efficient replacement motor for poultry feather picker machines. It replaces Leeson Cat #115751.00 and is suitable for washdown duty environments requiring USDA-approved food-safe paint and corrosion protection.

Key Specifications

• Horsepower: 3 hp
• RPM: 1740
• Voltage: 208-230/460V
• Amperage: 8.6/4.3 amps
• Enclosure: Washguard (washdown duty)
• Frame / Diameter: NEMA 56HZ
• Shaft Dimensions: 7/8" Diameter x 2 1/4" Length

Product Features & Fitment

The motor features a rigid base for stable mounting and includes shaft seals to protect against washdown conditions. It is epoxy painted for enhanced corrosion resistance and utilizes Class H insulation for high thermal endurance. This motor delivers extra high breakdown torque and operates on three-phase 60 Hz power.

Cross Reference

• Leeson Cat # 115751.00

Warranty

1 Year Manufacturer Warranty
