120379.00 Leeson | 3 hp 3450 RPM 145T 208-230/460V Aeration Fan Motor

120379.00 Leeson | 3 hp 3450 RPM 145T 208-230/460V Aeration Fan Motor

This Leeson 3 hp aeration fan motor is designed for industrial applications requiring reliable airflow. It serves as a direct replacement for motors in shaft-mounted or belt-driven fan systems, providing efficient and durable performance.

Key Specifications

• Horsepower: 3 hp
• RPM: 3450
• Voltage: 208-230/460V
• Amperage: 7.6/3.8 amps
• Enclosure: Totally Enclosed Air Over (TEAO)
• Frame / Diameter: NEMA 145T
• Shaft Dimensions: 7/8" x 2.25"
• Rotation: Reversible

Product Features & Fitment

This motor features a totally enclosed air over design, making it dust-tight and suitable for use within the airflow of the driven fan to provide environmental protection. It is finished with epoxy enamel for corrosion resistance in harsh atmospheres and lubricated with high-temperature Exxon POLYREX® EM lubricant. The motor includes grounding provisions and is fully gasketed for enhanced durability.

Warranty

1 Year Manufacturer Warranty
