Z406A Marathon 3 hp 3450 RPM 182JM Frame 115/208-230 Volts ODP Electric Motor

Marathon

Z406A Marathon 3 hp 3450 RPM 182JM Frame 115/208-230 Volts ODP Electric Motor

(No reviews) Write a Review

$895.62

$767.05

SKU MZ406A

UPC 7.23E+11

Shipping Calculated at Checkout

Compliance Tab /content/product_tabs/p65warnings.html

ON SALE LIMITED TIME DISCOUNT

Voltage 115/208/230V

Horsepower 3 HP

RPM 3450

Phase Single Phase

Frame 182JM

Enclosure ODP

Hertz 60 Hz

Amperage 32.0/16.1 Amps

Insulation Class Class F

Rotation Reversible

Mounting Rigid Base

Duty continuous duty

Current Stock:

Qty

Adding to cart… The item has been added

Description
Specifications

Description

3 hp 3450 RPM 182JM Frame, 32.0/16.1 amps 115/208-230V 60hz. single Phase Motor
Close Coupled Pump Motor - Rigid Base
Open Drip Proof (ODP) - Service Factor = 1.15
Class F Insulation; No Overload Protection
Reversible Rotation
Capacitor Start/Induction Run
One Year Manufacture Warranty

Close Coupled Pump Motor. Designed for continuous duty service on close Coupled pumps. Motor has rigid base and NEMA JM pump shaft. Wiring diagram on motor name plate.

182TCDW7318 Replaces Leeson Model C182K34DK1B; 131640.00, 131640; Dayton 26ZY36

Specifications

Compliance Tab	/content/product_tabs/p65warnings.html
ON SALE	LIMITED TIME DISCOUNT
Voltage	115/208/230V
Horsepower	3 HP
RPM	3450
Phase	Single Phase
Frame	182JM
Enclosure	ODP
Hertz	60 Hz
Amperage	32.0/16.1 Amps
Insulation Class	Class F
Rotation	Reversible
Mounting	Rigid Base
Duty	continuous duty
