121060.00 Leeson | 3 hp 3600 RPM 145TC Frame TEFC C-Face- Rigid Base 230V

121060.00 Leeson 3 hp 3600 RPM 145TC Frame TEFC C-Face Rigid Base 230V Motor

This Leeson general-purpose single-phase electric motor is designed for versatile industrial applications requiring a 3 hp motor with a C-face mount. It replaces similar 3 hp motors and is suitable for driving pumps, gearheads, and other machinery with compatible mounting configurations.

Key Specifications

• Horsepower: 3 hp
• RPM: 3600
• Voltage: 230 V
• Amperage: 13.0 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 145TC
• Shaft Dimensions: 7/8" diameter x 2 1/4" length, keyed shaft
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a rigid base mount combined with a C-face for flexible installation options. The shaft includes a keyway for secure coupling, and the C-face has four threaded bolt holes spaced 5 7/8" on center for mounting pumps or gearheads. A wiring diagram is provided on the motor nameplate to assist with proper electrical connections.

Warranty

1 Year Manufacturer Warranty
