3130-375 RAE | Right Angle Gearmotor - 90VDC, 510 RPM

1/8HP, 510 RPM
90 Volts DC, 1.76 FLA
13 Output Torque (Inch pounds)
Shaft: 5/8 x 1.80 inch, keyed
Gear ratio: 5:1
Enclosure rating: IP55

The G33 Series Single Worm Reduction Right Angle Gearbox, when matched with the appropriate RAE motor: is designed for applications requiring high output torques and a dependable, rugged design.

• Gearbox Designed to AGMA Standards
• Oil Filled
• Needle Bearings (Gearbox)
• High Energy Ceramic Magnets
• Double Shielded Ball Bearings (Motor)
• Dynamically Balanced Armature
• Reversible Design
• 36” “Cord
• TENV Design
• Externally Replaceable Brushes
• Auto-Hook Tang Type Commutator
• Class “F” Insulation

Cross References - This motor is a suggested replacement for the following motors. RPM, amps, shaft length, etc may not be exact, please double check your application and mounting requirement.
Leeson M1135041
WEG GH3305
Bodine 4140
RAE 3130375
