GT0084 Marathon 75 hp 1800 RPM 365T Frame 230/460V Open Drip Marathon Electric Motor
GT0084 Marathon 75 hp 1800 RPM 365T Frame 230/460V Open Drip Marathon Electric Motor
GT0084 Marathon 75 hp 1800 RPM 365T Frame 230/460V Open Drip Marathon Electric Motor
GT0084 Marathon 75 hp 1800 RPM 365T Frame 230/460V Open Drip Marathon Electric Motor
GT0084 Marathon 75 hp 1800 RPM 365T Frame 230/460V Open Drip Marathon Electric Motor
GT0084 Marathon 75 hp 1800 RPM 365T Frame 230/460V Open Drip Marathon Electric Motor

Marathon

GT0084 Marathon 75 hp 1800 RPM 365T Frame 230/460V Open Drip Marathon Electric Motor

(No reviews) Write a Review
$4,824.71
$4,130.80
SKU GT0084
UPC 7.23E+11
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 75 HP
RPM 1800
Phase Three Phase
Frame 365T
Enclosure ODP
Hertz 60 Hz
Amperage 172.0/86.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 75 hp 1800 RPM, 172.0/86.0 amps 230/460 Volts 60hz. Three Phase Motor
  • NEMA 365T Frame Keyed Shaft 2 3/8 " Diameter x 5 7/8"
  • Service Factor: 1.15 - overload protection = None
  • Reversible - Rigid Base Mount - Ball Bearings - Class F Insulation
  • Rolled Steel Construction
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase Electric motor. Motor has a rigid base mount with a keyed shaft. Wiring diagram on motor name plate. ODP = Open Drip Proof.

Marathon Model: 365TTDBD6060

Replaces Leeson 170029.60, B199720.00, 199720.00; Dayton 454X73

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 75 HP
RPM 1800
Phase Three Phase
Frame 365T
Enclosure ODP
Hertz 60 Hz
Amperage 172.0/86.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
