8D15P2C Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor
8D15P2C Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor
8D15P2C Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor
8D15P2C Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor

Nidec

8D15P2C Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor

(No reviews) Write a Review
$1,588.15
$1,417.49
SKU 8D15P2C
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 15 HP
RPM 1800
Phase Three Phase
Frame 254T
Enclosure TEFC
Hertz 60 Hz
Type Inverter Duty
Amperage 18.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 15 hp 1800 RPM, 18.0 amps 460 Volts 60 Hz Three Phase Motor
  • NEMA 254T Cast Iron Frame, Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 5 Year Manufacture Warranty, 3 year on inverter power

Corrosion resistant inverter duty motor is designed for use in petro-chemical and similar industries. Self-Certified Class 1, Division 2, Groups A, B, C, and D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GB56

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 15 HP
RPM 1800
Phase Three Phase
Frame 254T
Enclosure TEFC
Hertz 60 Hz
Type Inverter Duty
Amperage 18.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
