8D3P1C Nidec 3 hp 3600 RPM 182T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor

SKU:
8D3P1C
Weight:
80.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $631.00
Now: $563.60
Adding to cart… The item has been added
  • 3 hp 3600 RPM, 4.1 amps  460 Volts 60 Hz Three Phase Motor
  • NEMA 182T Cast Iron Frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 5 Year Manufacture Warranty, 3 year on inverter power

Corrosion resistant inverter duty motor is designed for use in petro-chemical and similar industries. Self-Certified Class 1, Division 2, Groups A, B, C, and D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GF39
