B315 Marathon 1/3 hp (1 speed) 115/208-230V 1725 RPM ODP 48Z Frame Cap Start Resilient Base Motor (Dayton 1AGG2)

B315 Marathon 1/3 hp (1 speed) 115/208-230V 1725 RPM ODP 48Z Frame Cap Start Resilient Base Motor (Dayton 1AGG2)

This Marathon electric motor is a 1/3 horsepower, single-speed unit designed for versatile industrial applications. It serves as a direct replacement for the Dayton 1AGG2 motor and compatible with Dayton ventilator models 308052, 1MBE7, and 2RB62, as well as Leeson 100110.00.

Key Specifications

• Horsepower: 1/3 hp
• RPM: 1725
• Voltage: 115/208-230 V
• Amperage: 5.8/3.1-2.9 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 48Z Frame
• Shaft Dimensions: 2" length x 1/2" diameter (flat shaft)
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features capacitor start and thermal auto protection with a service factor of 1.35. It is mounted on a resilient base and can be installed with the shaft oriented either vertically or horizontally. The motor includes Class B insulation and is suitable for applications requiring reliable, continuous operation.

Cross Reference

• Dayton 1AGG2 Motor
• Replacement Motor for 308052, 1MBE7, 2RB62 Dayton Ventilator
• Marathon Model: 048C17D2044
• Replaces Leeson 100110.00

Warranty

1 Year Manufacturer Warranty
