B607 Marathon 1/3 hp (1 speed) 277V 1800 RPM ODP 48Z Frame Resilient Base Blower Motor

B607 Marathon 1/3 hp 1-Speed 277V 1800 RPM ODP 48Z Frame Resilient Base Blower Motor

This Marathon blower motor is designed for reliable air movement in HVAC and industrial applications. It replaces standard 1/3 hp blower motors and is suitable for systems requiring a 1-speed, 277V motor with an open drip proof enclosure.

Key Specifications

• Horsepower: 1/3 hp
• RPM: 1800
• Voltage: 277 V
• Amperage: 2.5 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 48Z Frame
• Shaft Dimensions: 1 7/8" length x 1/2" diameter
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a resilient base for vibration reduction and ease of mounting. It operates on split phase power at 60 Hz and includes Class B insulation. The shaft orientation can be installed vertically or horizontally to fit various blower configurations. Thermal protection is not included.

Warranty

1 Year Manufacturer Warranty
