C133 Marathon 1/2 hp (1 speed) 115/230V 1800 RPM ODP 48 Frame Cap Start Resilient Base Motor

C133 Marathon 1/2 hp (1 speed) 115/230V 1800 RPM ODP 48 Frame Cap Start Resilient Base Motor

This Marathon 1/2 horsepower motor is designed for HVAC blower applications, providing reliable air movement in residential or commercial buildings. It serves as a direct replacement for motors requiring a 1-speed, capacitor start design with a resilient base mounting.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1800
• Voltage: 115/230 V, 60 Hz
• Amperage: 8.2/4.1 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 48 Frame
• Shaft Dimensions: 1 1/2" length x 1/2" diameter, flat shaft
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a capacitor start design with a service factor of 1.0 and automatic thermal protection for enhanced durability. It includes a resilient base for stable mounting and is suitable for both vertical and horizontal shaft orientations. The Class B insulation ensures reliable performance in typical HVAC environments.

Warranty

1 Year Manufacturer Warranty
