EP00525 TECO Westinghouse 5 hp 3600 RPM 184T Cast Iron 575V TEFC Severe Duty 3-Phase Motor

SKU:
EP00525
Weight:
145.00 LBS
Shipping:
Calculated at Checkout
$509.09
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 5 hp 3600 RPM, 4.58 amps 575 Volts 60Hz. Three Phase
  • NEMA 182/184T Frame, 2 3/4 x 1 1/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP54)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Applications: Crushers, Compressors, Mixers, Conveyors, Any Severe Duty Application
