EP01025 TECO Westinghouse 10 hp 3600 RPM 215T Cast Iron 575V TEFC Severe Duty 3-Phase Motor
EP01025 TECO Westinghouse 10 hp 3600 RPM 215T Cast Iron 575V TEFC Severe Duty 3-Phase Motor
EP01025 TECO Westinghouse 10 hp 3600 RPM 215T Cast Iron 575V TEFC Severe Duty 3-Phase Motor
EP01025 TECO Westinghouse 10 hp 3600 RPM 215T Cast Iron 575V TEFC Severe Duty 3-Phase Motor

TECO WESTINGHOUSE

EP01025 TECO Westinghouse 10 hp 3600 RPM 215T Cast Iron 575V TEFC Severe Duty 3-Phase Motor

(No reviews) Write a Review
$1,153.12
SKU EP01025
Shipping Calculated at Checkout
Voltage 575V
Horsepower 10 HP
RPM 3600
Phase Three Phase
Frame 215T
Enclosure TEFC
Hertz 60 Hz
Amperage 9.2 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Severe Duty
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 10 hp 3600 RPM, 9.2 amps 575 Volts 60Hz. Three Phase
  • NEMA 213/215T Frame, 3 3/8 x 1 3/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP54)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Applications: Crushers, Compressors, Mixers, Conveyors, Any Severe Duty Application

Specifications
Voltage 575V
Horsepower 10 HP
RPM 3600
Phase Three Phase
Frame 215T
Enclosure TEFC
Hertz 60 Hz
Amperage 9.2 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Severe Duty
!
