EP0102 TECO Westinghouse 10 hp 3600 RPM 215T Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor

EP0102 TECO Westinghouse 10 hp 3600 RPM 215T Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor

The EP0102 is a robust 10 horsepower, 3600 RPM three-phase motor designed for severe duty industrial applications. Ideal for replacing or upgrading motors in crushers, compressors, mixers, conveyors, and similar heavy-duty equipment.

Key Specifications

• Horsepower: 10 hp
• RPM: 3600
• Voltage: 230/460 V
• Amperage: 23.0/11.5 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC), IP54
• Frame / Diameter: NEMA 213/215T, Cast Iron Frame
• Shaft Dimensions: 3 3/8" x 1 3/8" Diameter, Keyed Shaft
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base for stable mounting and is suitable for inverter use in compliance with NEMA MG-1 Part 31.4.4.2, supporting a variable torque speed range of 20:1 and a constant torque range of 10:1. It is built with Class F insulation and designed for severe duty environments, ensuring reliable performance without thermal overload protection. The cast iron frame and TEFC enclosure provide durability and protection in demanding industrial settings.

Warranty

1 Year Manufacturer Warranty
