EP0302C TECO Westinghouse 30 hp 3600 RPM 286TSC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor
EP0302C TECO Westinghouse 30 hp 3600 RPM 286TSC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor
EP0302C TECO Westinghouse 30 hp 3600 RPM 286TSC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor
EP0302C TECO Westinghouse 30 hp 3600 RPM 286TSC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor

TECO WESTINGHOUSE

EP0302C TECO Westinghouse 30 hp 3600 RPM 286TSC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor

(No reviews) Write a Review
$2,575.55
SKU EP0302C
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 30 HP
RPM 3600
Phase Three Phase
Frame 286TSC
Enclosure TEFC
Hertz 60 Hz
Amperage 33.2 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Severe Duty
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 30 hp 3600 RPM, 66.4/33.2 amps 230/460 Volts 60Hz. Three Phase
  • NEMA 286TSC Frame, 3 x 1 5/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP54)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Applications: Crushers, Compressors, Mixers, Conveyors, Any Severe Duty Application

Specifications
Voltage 230/460V
Horsepower 30 HP
RPM 3600
Phase Three Phase
Frame 286TSC
Enclosure TEFC
Hertz 60 Hz
Amperage 33.2 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Severe Duty
!
