FF100E1EV Nidec 100 hp 3600 RPM 3-phase 365JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF100E1EV Nidec 100 hp 3600 RPM 3-phase 365JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF100E1EV Nidec 100 hp 3600 RPM 3-phase 365JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF100E1EV Nidec 100 hp 3600 RPM 3-phase 365JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor

Nidec

FF100E1EV Nidec 100 hp 3600 RPM 3-phase 365JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor

(No reviews) Write a Review
$12,593.65
$11,244.36
SKU FF100E1EV
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 100 HP
RPM 3600
Phase Three Phase
Frame 365JP
Enclosure ODP
Hertz 60 Hz
Amperage 227/113 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 100 HP 3600 RPM, 227/113 amps, 230/460V 60 Hz, 3 Phase.
  • NEMA 365JP Cast Iron Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings,

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, HH17

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 100 HP
RPM 3600
Phase Three Phase
Frame 365JP
Enclosure ODP
Hertz 60 Hz
Amperage 227/113 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
