FF40E1EV Nidec 40 hp 3600 RPM 3-phase 286JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF40E1EV Nidec 40 hp 3600 RPM 3-phase 286JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF40E1EV Nidec 40 hp 3600 RPM 3-phase 286JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF40E1EV Nidec 40 hp 3600 RPM 3-phase 286JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor

Nidec

FF40E1EV Nidec 40 hp 3600 RPM 3-phase 286JP Frame 230/460V ODP Vertical Close-Coupled Fire Pump Motor

(No reviews) Write a Review
$5,310.70
$4,741.57
SKU FF40E1EV
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 40 HP
RPM 3600
Phase Three Phase
Frame 286JP
Enclosure ODP
Hertz 60 Hz
Amperage 91.0/46.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 40 HP 3600 RPM, 91.0/46.0 amps, 230/460V 60 Hz, 3 Phase.
  • NEMA 286JP Rolled Steel Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings,

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, HM47

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 40 HP
RPM 3600
Phase Three Phase
Frame 286JP
Enclosure ODP
Hertz 60 Hz
Amperage 91.0/46.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
