FX03BK002 | 3 HP 3600 RPM 56HC 208-230/460V 3 Phase TEFC, FLEX-IN-1 Marathon Electric Motor

FX03BK002 | 3 HP 3600 RPM 56HC 208-230/460V 3 Phase TEFC, FLEX-IN-1 Marathon Electric Motor

The Marathon FLEX-IN-1™ electric motor is a versatile, high-performance replacement motor designed to fit hundreds of discontinued or out-of-stock brand name motors. Ideal for industrial applications requiring a reliable 3 HP, 3600 RPM motor with flexible mounting options and robust construction.

Key Specifications

• Horsepower: 3 HP
• RPM: 3600
• Voltage: 208-230/460 V
• Amperage: 8.2-7.6/3.8 A
• Enclosure: TEFC (Totally Enclosed Fan Cooled)
• Frame / Diameter: 56HC
• Bearings: Double-sealed ball bearings

Product Features & Fitment

This motor features the patent-pending FLEX-IN-1™ multi-mount design with a repositionable bolt-on base and C-face, allowing rapid reconfiguration of the conduit box and mounting base without the need for additional parts. The conduit box is rotatable 180° with knockouts on all sides, and the fan guard can be rotated in 90° increments for optimal alignment. The repositionable combination base supports NEMA 56, 56H, 143T, and 145T mounting patterns and can be adjusted for F-1, F-2, or F-3 conduit box locations. The motor is inverter duty rated (10:1 CT) with Class F insulation, ensuring durability and compatibility with variable frequency drives.
