sale
Marathon
J063A Marathon 1 hp 3-Phase Jet Pump Motor 3600 RPM 230/460V TEFC 56J Frame (rigid base)
(No reviews)
Write a Review
Write a Review
Marathon
J063A Marathon 1 hp 3-Phase Jet Pump Motor 3600 RPM 230/460V TEFC 56J Frame (rigid base)
$575.58
$499.79
SKU
MJ063A
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage
230/460V
Horsepower
1 HP
RPM
3600
Phase
Three Phase
Frame
56J
Enclosure
TEFC
Hertz
60 Hz
Amperage
3.0/1.5 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class B
Rotation
Reversible
Mounting
Rigid Base
- 1 hp 3600 RPM, 3.0/1.5 amps, 230/460 volts, 3 phase
- NEMA 56J Frame, 5'8" dia. by 1-5/8" long threaded stainless steel shaft, 60 Hz
- Service Factor: 1.15, Overload protection: None
- Rigid base, Reversible rotation, Ball Bearings; Class B Insulation
- 1 Year Manufacture Warranty
Spa pump motor. Not for pool use due to lack of suction cut-off. TEFC = Totally Enclosed Fan-Cooled, 056T34F99029
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM |
| Voltage | 230/460V |
| Horsepower | 1 HP |
| RPM | 3600 |
| Phase | Three Phase |
| Frame | 56J |
| Enclosure | TEFC |
| Hertz | 60 Hz |
| Amperage | 3.0/1.5 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.15 |
| Insulation Class | Class B |
| Rotation | Reversible |
| Mounting | Rigid Base |
