sale
Marathon
K158 Marathon 1/2 hp 208-230/460V 1800 RPM 3-Phase 56 Frame TEFC (rigid base) Motor
(No reviews)
Write a Review
Write a Review
Marathon
K158 Marathon 1/2 hp 208-230/460V 1800 RPM 3-Phase 56 Frame TEFC (rigid base) Motor
$439.99
$282.56
SKU
MK158
UPC
7.23E+11
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage
208/230/460V
Horsepower
1/2 HP
RPM
1800
Phase
Three Phase
Frame
56
Enclosure
TEFC
Hertz
60 Hz
Amperage
2.2/1.1 Amps
Bearings
Ball Bearings
Service Factor
1.25
Mounting
Rigid Base
- 1/2 hp 1800 RPM, 2.1-2.2/1.1 amps 208-230/460 Volts 60hz. Three Phase
- NEMA 56 frame, Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.25, Thermal Overload Protection: None
- Rigid Base, Reversible, Ball Bearings, Class A Insulation
- 1 Year Manufacture Warranty
This is a general purpose three phase motor with a rigid base mount. Shaft has keyway. General purpose motors are for use in situations not having special requirements. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled
Marathon # 5K35MNB117
Replaces Leeson C4T17FH1D, 100913.00
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM |
| Voltage | 208/230/460V |
| Horsepower | 1/2 HP |
| RPM | 1800 |
| Phase | Three Phase |
| Frame | 56 |
| Enclosure | TEFC |
| Hertz | 60 Hz |
| Amperage | 2.2/1.1 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.25 |
| Mounting | Rigid Base |
