- 1/6 hp, 340 RPM, 2.0/1.0 amps, 115/230 Volts
- Gear Ratio = 5
- Torque 23 inch pounds
- Over Hung Pounds = 235
- TEFC = Totally Enclosed Fan Cooled
- Class F Insulation; Service Factor 1.0
- Permanent split capacitor design rated for 115/230VAC 60/50 HZ input
- Rotation = Reversible
- Keyed Shaft, Ball Bearings
- One Year Manufacture Warranty.
Features: This worm-type right-angle gearing features hardened, steel worm with bronze worm wheel for long life and quiet operation. Precision machined aluminum housings are used. Gearbox has ball bearings. The housing is sealed and lubrication is permanent with an oil bath. The output shaft is field interchangeable from left hand style to right hand style by reassembly. Optional conduit box # M1760012 & Optional base mount M1760006 available.
CM38P17FZ20B, M1145041.00
Suitable replacement for Baldor GC3324, Bison 026-756-8005, Bodine 0645 - Please double check the specs to make sure it will work for your application
