NP0016C TECO-Westinghouse 1 hp 1200 RPM 145TC 230/460V TEFC Severe Duty Petro-Chem 3-Ph Motor

SKU:
NP0016C
Weight:
49.00 LBS
Shipping:
Calculated at Checkout
$386.80
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 1 hp 1200 RPM, 3.46/1.73 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 145TC Frame, 2 1/8 x 7/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP56)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

For use in Severe Duty Applications Having Explosive Gases. Certified for Class 1, Division 2, Groups B,C,D
