NP0052 TECO Westinghouse 5 hp 3600 RPM 182T Frame 230/460V TEFC 3-Phase Motor

SKU:
NP0052
Weight:
88.00 LBS
Shipping:
Calculated at Checkout
$463.20
Adding to cart… The item has been added

TECO WESTINGHOUSE MAX-PE, NEMA PREMIUM ELECTRIC MOTOR
SEVERE DUTY RATED

  • 5 hp 3600 RPM, 11.4/5.72 amps 230/460 Volts 60hz. Three Phase
  • NEMA 184T Frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Cast Iron Construction, Enclosure: Totally Enclosed Fan Cooled (IP54)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Applications: Fans & Blowers, Pumps, Crushers, Compressors, Mixers, Conveyors
